Are you looking to have your reel spooled? You can have us do it and be reassured that it will be done right. Purchase the line you want on the reel here and let us know how you want it done in the notes upon checkout. Easy as that.
Trinidad is a name that resonates with all saltwater anglers and has earned an impeccable reputation for power and reliability. Shimano's quest for the Trinidad A was no easy task: lighter, smaller and more compact were the desired key physical characteristics — and they were accomplished. The performance goal was to build the best casting reel in this category: We shattered our targets and have built a reel for casting which all other casting reels will be measured by.
X-Ship Baitcasting
X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.
HAGANE Body Baitcasting
The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.
This pairs very well with our Dogfish Stik Conventional Jigging Rod, Dogfish Stik Conventional Blue Water Series or our Dogfish Stik Conventional Kingfish Series
TRINIDAD 16A
-
Body Material: Aluminum
-
Max Drag (lbs): 25
-
Line Capacity Braid (yds/lb): 530/50 • 330/65 • 250/80
-
Weight (oz): 19.4
-
Bearings: 9
TRINIDAD 20A
-
Body Material: Aluminum
-
Max Drag (lbs): 25
-
Line Capacity Braid (yds/lb): 710/50 • 375/65 • 310/80
-
Weight (oz): 19.8
-
Bearings: 9
TRINIDAD 30A
-
Body Material: Aluminum
-
Max Drag (lbs): 25
-
Line Capacity Braid (yds/lb): 1015/50 • 515/65 • 415/80
-
Weight (oz): 20.5
-
Bearings: 9
HAGANE BODY
The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.
X-SHIP
X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.
HEG
HEG consists of not only the gears, but also the frame, setplate, and handle-side sideplate. First we increased the size of the drive gear and the pinion gear to offer increased leverage and power. By using a one-piece frame that incorporates the setplate and adding a one-piece stamped sideplate, we have eliminated flex in the drive train that causes gears to bind under pressure.
Shimano's proprietary EI surface treatment of the spool and body creates corrosion resistance that is more than double compared to conventional surface treatments.
CROSS CARBON DRAG
The Cross Carbon Drag material provides a wider range of drag settings compared to traditional drag materials. The Cross Carbon Drag provides the smoothest Shimano drag performance ever while providing anglers with increased durability.
SUPER FREE SPOOL
Super Free Spool eliminates friction on the spool shaft during the cast. Standard baitcasting reels are constructed in a way that when the clutch bar is pressed down, the pinion gear is freed and can actually drag on the spool shaft. This creates friction that can limit the length of a cast. But baitcasting reels with Super Free Spool are constructed so that the pinion gear is supported by a ball bearing. When the clutch is disengaged in preparation for a cast, the pinion gear and spool shaft are kept in perfect alignment. The result: zero friction is placed upon the spool shaft and enhances casting performance.
S A-RB
S A-RB bearings are put through the same process as Shimano’s A-RB bearings but feature shields on both sides of the bearings. These shields reduce the possibility of salt or sand inhibiting rotation of the bearing.
S-COMPACT BODY
S-Compact Body allows for all-day comfort and improved fishability by making the palming side plate up to 25% smaller than the A-Side plate.
SKU
|
SKU
|
|
SKU
|
GEAR RATIO
|
MAX DRAG (LB)
|
WEIGHT (OZ)
|
MONO LINE CAPACITY (LB-YD)
|
POWERPRO LINE CAPACITY (LB-YD)
|
LINE RETRIEVE PER CRANK (IN)
|
BALL BEARINGS
|
| TN12A |
6.3 |
17 |
13.9 |
12/300, 15/215, 20/150 |
40/280, 50/275, 65/175 |
38 |
8/1 |
| TN14A |
6.3 |
17 |
14.8 |
12/420, 15/280, 20/200 |
40/375, 50/370, 65/240 |
38 |
8/1 |
| TN16A |
6.2 |
25 |
19.4 |
15/420, 20/300, 25/240 |
50/530, 65/330, 80/250 |
46 |
8/1 |
| TN16NA |
6.2 |
25 |
19.3 |
15/260, 20/200, 25/150 |
50/370, 65/235, 80/190 |
46 |
8/1 |
| TN20A |
6.2 |
25 |
19.8 |
20/410, 25/330, 30/280 |
50/710, 65/375, 80/310 |
46 |
8/1 |
| TN30A |
6.2 |
25 |
20.5 |
- |
50/1015, 65/515, 80/415 |
46 |
8/1 |
Price checked on 11-14-24
